SI 6130 A/B Automotive electronics White Silicone potting compound Sealant
SI 6130 A/B Automotive electronics White Silicone potting compound Sealant
Product features and uses:
SI 6130A/B is suitable for potting protection of various components. It can be deeply cured, and the two components have good fluidity after mixing. The operation time can adjust the proportion of curing agent according to the temperature. There is no need to use other primer before use, which has a good bonding effect on most materials, and is suitable for the fixing of accessories and waterproof, dustproof and anti-leakage.
l Two component liquid silicone rubber, condensation dealcoholization type
l Low viscosity, easy to process, strong operability
l Low hardening shrinkage, no corrosion and no stress
l Excellent high temperature electrical insulation and stability
l Excellent adhesion, good water resistance, moisture resistance
Application fields:
l Automotive electronics, modules
l Sensors of all kinds
l Power control modules
l Solar module junction box
l LED spotlights, wall wash lights, strip lights, LED fluorescent lights
Pre - and post-cure characteristics
Test items | Test Standard | 6130 White | |
Appearance | A | Visual | White fluid |
B | Light yellow liquid | ||
Viscosity,cps,25℃ | A | GB/T 2794-2022 | 5,000±500 |
B | 15-30 | ||
Density,g/cm3,25℃ | A | GB/T 13354-1992 | 1.3±0.05 |
B | 1±0.05 | ||
Mixing ratio | Mass ratio | A: B = 10:1 | |
Viscosity after mixing,cps,25℃ | GB/T 2794-2022 | 3,000±500 | |
Operating time after mixing,min | GB/T 2794-2022 | 20-40 | |
Tack free time,min | GB/T 13477.5-2002 | 60-120 | |
Hardness, SHORE A | GB/T 531.1-2008 | 45±5 | |
Tensile strength,MPa | GB/T 528-2009 | >1.5 | |
Elongation at break | GB/T 528-2009 | >80% | |
Shear strength,Al-Al, MPa | GB/T 7124-2008 | 0.6 | |
Coefficient of linear expansion, ppm | GB/T 1036-2008 | 200 | |
Thermal conductivity, W/m.K | GB/T 10297-2015 | 0.45 | |
Loss factor (1 MHz) | GB/T 1693-2007 | 0.01 | |
Dielectric strength,kV/mm,25℃ | GB/T 1695-2005 | ≥20 | |
Volume resistance DC 500V,Ω·cm | GB/T 1692-2008 | ≥1.0×1014 | |
Dielectric constant (1 MHz) | GB/T 1693-2007 | 3.2 | |
Long-term use temperature range, ℃ | GBT 20028-2005 | - 50 ∽ 150 | |
PS: Operation time is tested with the amount of glue dispensed 140 g.
Curing state All data were determined at 25℃, 55%RH after 7 days of adhesive curing.
